| ID |
Part No. |
Description |
Quantity |
Req |
Our Price |
| 1 |
1017696 |
1017696 - SUB ASM- ACCELERATOR PEDAL |
|
1 |
$27.72
Each |
| 2 |
1013871 |
1013871 - PAD- ACCELERATOR PEDAL |
|
1 |
$3.48
Each |
| 3 |
7716 |
7716 - SCREW- #10-16 TYPE AB SHT MTL |
|
4 |
$0.30
Each |
| 4 |
1218 |
1218 - SCREW- 5/16-18 X 1.25 HX HD CP |
|
1 |
$0.50
Each |
| 5 |
1241 |
1241 - WASHER- 5/16 TYPE A FLAT |
|
3 |
$0.24
Each |
| 6 |
102026001 |
102026001 - ACCEL. PIVOT ROD ASM. KIT |
|
1 |
$16.68
Each |
| 7 |
7473 |
7473 - LOCKNUT- 5/16-18 NYLON HEX |
|
2 |
$0.24
Each |
| 8 |
332 |
332 - WASHER- 1/4 TYPE A NARROW FLAT |
|
4 |
$0.24
Each |
| 9 |
101862001 |
101862001 - SCREW- 1/4-20 X 1.500 FLANGE |
|
2 |
$1.50
Each |
| 10 |
1017424 |
1017424 - BEARING- PIVOT SUPPORT |
|
1 |
$4.92
Each |
| 11 |
1015661 |
1015661 - NUT- LOCK HX FLANGED 1/4-20 |
|
2 |
$0.60
Each |
| 12 |
101817401 |
101817401 - RETAINER- SPRING |
|
1 |
$11.34
Each |
| 13 |
101796201 |
101796201 - SPRING- ACCELERATOR RETURN |
|
1 |
$10.20
Each |
| 14 |
1017378 |
1017378 - CUP- SPRING |
|
1 |
$2.64
Each |
| 15 |
1017380 |
1017380 - BUMPER- SPRING RETURN |
|
1 |
$1.44
Each |
| 16 |
1017400 |
1017400 - ACTUATOR LEVER ASM |
|
1 |
$7.20
Each |
| 17 |
101804201 |
101804201 - WASHER- 1/2 PLASTIC |
|
1 |
$0.36
Each |
| 18 |
1017433 |
1017433 - ASM- TOWBAR CLEVIS |
|
1 |
$39.56
Each |
| 19 |
101804301 |
101804301 - SCREW- #8 X .500 HX HD HI-LO |
|
2 |
$0.38
Each |
| 20 |
1011694 |
1011694 - ACCELERATOR BRACKET-BRG ASM |
|
1 |
$15.60
Each |
| 21 |
101861901 |
101861901 - SCREW- 1/4-20 X 1.125 HEX CAP |
|
4 |
$0.42
Each |
| 22 |
8754 |
8754 - LOCKNUT- 3/8-16 HEX |
|
1 |
$0.36
Each |
| 23 |
101187702 |
101187702 - HILL BRK LATCH KIT 9529<R |
|
1 |
$24.24
Each |
| 24 |
8233 |
8233 - LOCKNUT- 1/4-20 NYLON INSERT |
|
4 |
$0.36
Each |
