| ID |
Part No. |
Description |
Quantity |
Req |
Our Price |
| 1 |
8639 |
8639 - TIE WRAP- 11 INCH NYLON |
|
4 |
$0.36
Each |
| 2 |
1016859 |
1016859 - KIT- REVERSE BUZZER |
|
1 |
$23.28
Each |
| 3 |
1016851 |
1016851 - BUZZER- 9-48 VDC REVERSE |
|
1 |
$12.60
Each |
| 4 |
1016849 |
1016849 - #4-24 X 5/16 INCH PAN HD SCR |
|
2 |
$0.24
Each |
| 5 |
1016857 |
1016857 - WIRE ASSEMBLY BLACK #18 |
|
1 |
Each |
| 5 |
101826401 |
101826401 - KEYSWITCH- 12V ON/OFF/START |
|
1 |
$32.14
Each |
| 6 |
1017721 |
1017721 - VOLTAGE LIMITER 1.4 V DROP |
|
1 |
$13.44
Each |
| 6 |
1016 |
1016 - LOCKWASHER- #10 SPLIT |
|
1 |
$0.30
Each |
| 7 |
1010909 |
1010909 - SCREW- #10-32 X 1.25 RD HD MCH |
|
1 |
$0.30
Each |
| 8 |
183 |
183 - WASHER- #10 TYPE A FLAT |
|
4 |
$0.30
Each |
| 10 |
7893 |
7893 - NUT- #10-32 HEX |
|
1 |
$0.30
Each |
| 11 |
1016356 |
1016356 - TERMINAL BLOCK W/INSULATOR |
|
1 |
$7.68
Each |
| 12 |
1013357 |
1013357 - RIVET- 5/32 ALUMINUM POP |
|
2 |
$0.38
Each |
| 13 |
4029 |
4029 - HORN (JUBILEE 28-12V) |
|
1 |
$41.76
Each |
| 14 |
7820 |
7820 - WASHER- LOCK TOOTH- INT. 5/16 |
|
1 |
$0.30
Each |
| 15 |
1012528 |
1012528 - NUT- M8-1.25 HEX |
|
1 |
$0.30
Each |
| 16 |
1011825 |
1011825 - HORN BRACKET |
|
1 |
$4.44
Each |
| 17 |
304 |
304 - SCREW- 1/4-20 X 1.0 HEX HD CAP |
|
2 |
$0.42
Each |
| 18 |
332 |
332 - WASHER- 1/4 TYPE A NARROW FLAT |
|
2 |
$0.24
Each |
| 19 |
8233 |
8233 - LOCKNUT- 1/4-20 NYLON INSERT |
|
2 |
$0.36
Each |
| 20 |
101689701 |
101689701 - HEADLIGHT ASSEMBLY - LEFT |
|
1 |
$92.52
Each |
| 21 |
101689702 |
101689702 - HEADLIGHT ASSEMBLY - RIGHT |
|
1 |
$92.52
Each |
| 22 |
1017066 |
1017066 - WIRE HARNESS-HEADLIGHT |
|
1 |
$24.48
Each |
| 23 |
1017059 |
1017059 - BULB COLLAR LOCK |
|
1 |
$5.04
Each |
| 24 |
1017060 |
1017060 - HALOGEN BULB |
|
1 |
$18.72
Each |
| 25 |
1017061 |
1017061 - HEADLIGHT LENS |
|
2 |
$35.76
Each |
| 26 |
1017064 |
1017064 - MOUNTING BRKT |
|
2 |
$2.52
Each |
| 27 |
7893 |
7893 - NUT- #10-32 HEX |
|
2 |
$0.30
Each |
| 28 |
1013461 |
1013461 - SCREW- #10-16 HEX HEAD HI-LO |
|
2 |
$0.36
Each |
| 29 |
1017065 |
1017065 - HEADLIGHT RETAINER |
|
1 |
$7.92
Each |
| 30 |
1017062 |
1017062 - TURN SIGNAL LENS ASSY |
|
1 |
$12.24
Each |
| 31 |
1016880 |
1016880 - HEADLIGHT BEZEL - LEFT 93 |
|
1 |
$13.32
Each |
| 32 |
1016879 |
1016879 - HEADLIGHT BEZEL RIGHT 93 |
|
1 |
$13.32
Each |
| 34 |
1606 |
1606 - RIVET- 3/16 X .500 ALUM POP |
|
3 |
$0.38
Each |
