| ID |
Part No. |
Description |
Quantity |
Req |
Our Price |
| 1 |
101829401 |
101829401 - STARTER/GENERATOR CCW |
|
1 |
$439.32
Each |
| 4 |
1012993 |
1012993 - COMMUTATOR END BELL |
|
1 |
$60.48
Each |
| 5 |
357 |
357 - LOCKWASHER- 3/8 SPLIT |
|
3 |
$0.30
Each |
| 6 |
706 |
706 - NUT- HEX 3/8-16 |
|
3 |
$0.30
Each |
| 7 |
705 |
705 - SCREW- CAP-HEX HD 3/8-16X1.25 |
|
9 |
$0.64
Each |
| 8 |
1014203 |
1014203 - STARTER/GEN BRKT. ASSEMBLY |
|
1 |
$18.90
Each |
| 9 |
1012442 |
1012442 - SCREW- M8-1.25 X 18MM HEX HEAD |
|
2 |
$0.48
Each |
| 10 |
7174 |
7174 - LOCKWASHER- 5/16 SPLIT |
|
2 |
$0.24
Each |
| 12 |
1241 |
1241 - WASHER- 5/16 TYPE A FLAT |
|
3 |
$0.24
Each |
| 14 |
1012335 |
1012335 - STARTER GENERATOR ADJ BRACKET |
|
1 |
$11.94
Each |
| 15 |
1012463 |
1012463 - BOLT- 3/8-16 X .875 HEX HEAD |
|
1 |
$0.60
Each |
| 16 |
1012341 |
1012341 - STARTER / GENERATOR PULLEY |
|
1 |
$29.04
Each |
| 16 |
1014289 |
1014289 - PULLEY- STARTER-GENERATOR |
|
1 |
$40.80
Each |
| 19 |
1015932 |
1015932 - BOLT- 5/16-18 RD HD SQ NECK |
|
1 |
$0.56
Each |
| 21 |
1012999 |
1012999 - END BELL OUTPUT SHAFT |
|
1 |
$52.44
Each |
| 22 |
1242 |
1242 - NUT- 5/16-18 HEX |
|
1 |
$0.30
Each |
| 24 |
1013001 |
1013001 - BEARING- OUTPUT SHAFT BALL |
|
1 |
$9.48
Each |
| 25 |
1013002 |
1013002 - BEARING RETAINER |
|
1 |
$11.98
Each |
| 26 |
1013003 |
1013003 - KEY- STARTER GENERATOR |
|
1 |
$4.44
Each |
| 28 |
1013005 |
1013005 - BEARING- COMMUTATOR BALL |
|
1 |
$6.96
Each |
| 32 |
1013009 |
1013009 - SCREW- POLE PIECE |
|
4 |
$2.77
Each |
| 33 |
1013010 |
1013010 - FIELD COIL ASSEMBLY |
|
1 |
$159.84
Each |
| 35 |
1013011 |
1013011 - BRUSH HOLDER ASSEMBLY (CCW) |
|
1 |
$35.28
Each |
| 41 |
101876501 |
101876501 - NUT & SCREW SET |
|
1 |
$4.16
Each |
